KORAD KA3010D DC Power Supply 30V 10A Precision Adjustable DC Digital Control Power Supply

KORAD KA3010D DC Power Supply 30V 10A Precision Adjustable DC Digital Control Power Supply

Product Features :-

• 30V/10A Full Digital Power Control Single
• 10MV/1MA High Accuracy And Resolution
• Low Noise And Ripple
• CV/CC Given Voltage And Constant Current Mode
• Highly Reliable OCP, OVP, Arbitrarily Set Protection
• Built-in Set Of Parameters Stored
• Outputs A Switch Control
• Power And Memory Function
• Keypad Lock To Prevent Misuse
• Intelligent Temperature Control Fan, Effectively Reduce The Noise
• Easy Alternative To Traditional Digital Power

Product Specification :-

• Input Voltage : 220V +/-10%
• Frequency Range : 50- 60HZ
• Operating Temperature : 32-104 ℉ (0-40 ºC)
• Operating Humidity : < 80%RH
• Storage Temperature : 32-158 ℉ (0-70 ºC)
• Storage Humidity : < 70%RH

Stable Voltage :-

• Output Voltage range : 0-30V Continuously Adjustable
• Setup Resolution : 10 MV
• Setup Accuracy : <0.05% +20 MV
• Ripple : < 1MVRMS
• Read Back Accuracy : 10 MV
• Temp. Coefficient : < 0.1% + 10MV
• Read Back Temp. Coefficient : < 100 PPM+10 MV

Stable Current :-

• Output Current Range : 0-10A Continuously Adjustable
• Setup Resolution : 1 MA
• Setup Accuracy : <0.1% +3 MA
• Ripple : < 3MARMS
• Read Back Accuracy : 1 MA
• Temp. Coefficient : < 0.1% + 5MA
• Read Back Temp. Coefficient : < 100 PPM+5 MA
